Automatic Capsule Filler Machine By Rich Packing
How to differentiate between granule powder filling capsule machine and oil liquid filling making soft capsule machine is something that our many customers want to know and care about. For the machinery for manufacturing hard shell hollow capsules and soft capsules are completely different, and the application scene and manufactured finished products are different.
*** Applications
*** Technical parameter
Production capacity |
90000 pcs/h |
Net weight of machine |
1200Kg |
Overall size of machine |
900×870×1950mm |
Power |
380/220V 50Hz |
Total power |
5.5KW |
No.of segment bores |
9 |
Vacuum |
40m3/h-0.04-0.08Mpa |
Dust collector |
24.5Kpa 210m3/h |
Noise |
<75DB(A) |
Making rate |
Empty capsule99.9% Full capsule99.8% |
Applicable capsule |
00,0,1,2,3,4,5# |
Filling error |
Western medicine:±3% Chinese medicine:±4% |
Applicable product |
Power、granule、pellet、tablet |
Packing size |
1490×1260×2150mm |
*** Configuration List
Item |
Specification |
Qty. |
Manufacturer |
Touch screen |
6AV6/648-0BC11-3AX0 |
1 |
Germany Siemens |
PLC |
6ES7/288-1ST20-0AA0 |
1 |
Germany Siemens |
AC Contactor |
3TB42 |
4 |
Germany Siemens |
Frequency converter |
VFD015 B21A |
1 |
Taiwan Delta |
Thermal relay |
3UA59 |
3 |
Germany Siemens |
Button |
ZB2-BA3C |
3 |
Schneider |
Main Motor |
CH-30-1100W |
1 |
Dongli |
Cam |
RU-83DS-10 RU-83DS-6 |
2 |
Taiwandaojin |
Vacuum pump(wet) |
SK-0.5A |
1 |
Shanghai |
Dust collector |
XLJ Series |
1 |
Self-made |
Linear bearing |
LM10UU |
40 |
Korea SAMICK |
Linear bearing |
LM12UU |
48 |
Korea SAMICK |
Linear bearing |
LM20UU |
8 |
Korea SAMICK |
Linear bearing |
LM40UU |
4 |
Korea SAMICK |
Roller bearing |
CF6B |
10 |
Japan IKO |
Roller bearing |
CF12B |
5 |
Japan IKO |
Roller bearing |
CF18B |
1 |
Japan IKO |
Deep groove ball bearing |
6200 |
10 |
JapanNSK |
If you want making the fully enclosed soft capsule filled with materials like fish oil, then you should buy the soft shell capsule encapsulating machine.
But if you need to fill the powders or pellets into hard shell empty capsules, then it is the ours NJP series capsule filling machine of Rich Packing or the CGN semi-automatic capsule filling machines.
The differences between these two models are that the NJP is the fully auto making type, while the CGN series is the semi automatic working model.
*** Why choose us?
The distinguished nodes are whether the materials loading or the entire production process is operated by the machine itself program, so that the customers can judge whether the machine is fully automatic or semi-automatic type.
In order to improve the capsuling production efficiency of capsule filling, we have specially configured the high-stability DS indexing box inside the automatic NJP capsule filling machine.
This two devices are used to improve the working speed and the stability of the entire machinery, which can achieve high running speed operation while maintaining long-term stability and durability.
