Automatic Capsule Making Machine 000
This NJP-1500 capsule filling machine automatic is very suitable for all kinds of mass production due to its high capability of 24-hour continuous work, rapidly high efficiency rate and automatic operation. All parts of this making capsule equipment is in high degree of the safety and all powder or the granules can be filled accurately. The error rate of this 1500D equipment is very low and this equipment is straightforward to be cleaned and maintained.
*** Applications
*** Technical parameter
Production capacity of capsule filling machine |
90000 pcs/h |
Net weight of machine |
1200Kg |
Overall size of machine |
900×870×1950mm |
Power of capsule making machine |
380/220V 50Hz |
Total power |
5.5KW |
No.of segment bores |
9 |
Vacuum |
40m3/h-0.04-0.08Mpa |
Dust collector |
24.5Kpa 210m3/h |
Noise |
<75DB(A) |
Making rate |
Empty capsule99.9% Full capsule99.8% |
Applicable capsule |
00,0,1,2,3,4,5# |
Filling error |
Western medicine:±3% Chinese medicine:±4% |
Applicable product |
Power、granule、pellet、tablet |
Packing size |
1490×1260×2150mm |
*** Configuration List
Item |
Specification |
Qty. |
Manufacturer |
Touch screen |
6AV6/648-0BC11-3AX0 |
1 |
Germany Siemens |
PLC |
6ES7/288-1ST20-0AA0 |
1 |
Germany Siemens |
AC Contactor |
3TB42 |
4 |
Germany Siemens |
Frequency converter |
VFD015 B21A |
1 |
Taiwan Delta |
Thermal relay |
3UA59 |
3 |
Germany Siemens |
Button |
ZB2-BA3C |
3 |
Schneider |
Main Motor |
CH-30-1100W |
1 |
Dongli |
Cam |
RU-83DS-10 RU-83DS-6 |
2 |
Taiwandaojin |
Vacuum pump(wet) |
SK-0.5A |
1 |
Shanghai |
Dust collector |
XLJ Series |
1 |
Self-made |
Linear bearing |
LM10UU |
40 |
Korea SAMICK |
Linear bearing |
LM12UU |
48 |
Korea SAMICK |
Linear bearing |
LM20UU |
8 |
Korea SAMICK |
Linear bearing |
LM40UU |
4 |
Korea SAMICK |
Roller bearing |
CF6B |
10 |
Japan IKO |
Roller bearing |
CF12B |
5 |
Japan IKO |
Roller bearing |
CF18B |
1 |
Japan IKO |
Deep groove ball bearing |
6200 |
10 |
JapanNSK |
Capsule making machine NJP-1500 has zero noise to create a quiet environment for people during the whole operation process.
Zero wiping and zero damage due to zero deviation of this making capsule equipment to ensure the quality of the capsule.
Both the 1500d capsule filling machine's the upper and lower dies are dustless and no dirt to rapidly improve the effect of sowing due to the cleaning system of the on-line air pressure die.
*** Why choose us?
This model of capsule making machine is excellent in printing code, the date of production, etc to meets the clients' needs. This making capsule equipment is convenient in replacing all kinds of filling rods and the mold can be rapidly replaced in the time as short as in 15 minutes. This 1500D equipment is excellent in reducing the waste and highly improving the economic benefit due to its recycling rate of 100% of the powder recovery setting.
