Full Automatic Filling Capsule Machine 000
NJP-1500D automatic 00 capsule making machine is popular among customers due to its excellent quality, the excellent performance, the stabilized system, the straightforward operation, and etc. This kind of filling capsule machine has been sold to numerous countries and rigions and enjoys a high reputation among customers.
it is loved by many companies, 1500D it is very attractive. The people at home and abroad all appreciate its profession and numerous advantages, such as 1500D it has the high degree of safety and very nice to the environment, it is a green product.
*** Applications
*** Technical parameter
Production capacity capsule filler machine |
90000 pcs/h |
Net weight of machine |
1200Kg |
Overall size of machine |
900×870×1950mm |
Power of making capsule machine |
380/220V 50Hz |
Total power |
5.5KW |
No.of segment bores |
9 |
Vacuum |
40m3/h-0.04-0.08Mpa |
Dust collector |
24.5Kpa 210m3/h |
Noise |
<75DB(A) |
Making rate |
Empty capsule99.9% Full capsule99.8% |
Applicable capsule |
00,0,1,2,3,4,5# |
Filling error |
Western medicine:±3% Chinese medicine:±4% |
Applicable product |
Power、granule、pellet、tablet |
Packing size |
1490×1260×2150mm |
*** Configuration List
Item |
Specification |
Qty. |
Manufacturer |
Touch screen |
6AV6/648-0BC11-3AX0 |
1 |
Germany Siemens |
PLC |
6ES7/288-1ST20-0AA0 |
1 |
Germany Siemens |
AC Contactor |
3TB42 |
4 |
Germany Siemens |
Frequency converter |
VFD015 B21A |
1 |
Taiwan Delta |
Thermal relay |
3UA59 |
3 |
Germany Siemens |
Button |
ZB2-BA3C |
3 |
Schneider |
Main Motor |
CH-30-1100W |
1 |
Dongli |
Cam |
RU-83DS-10 RU-83DS-6 |
2 |
Taiwandaojin |
Vacuum pump(wet) |
SK-0.5A |
1 |
Shanghai |
Dust collector |
XLJ Series |
1 |
Self-made |
Linear bearing |
LM10UU |
40 |
Korea SAMICK |
Linear bearing |
LM12UU |
48 |
Korea SAMICK |
Linear bearing |
LM20UU |
8 |
Korea SAMICK |
Linear bearing |
LM40UU |
4 |
Korea SAMICK |
Roller bearing |
CF6B |
10 |
Japan IKO |
Roller bearing |
CF12B |
5 |
Japan IKO |
Roller bearing |
CF18B |
1 |
Japan IKO |
Deep groove ball bearing |
6200 |
10 |
JapanNSK |
NJP-1500D fully automatic capsule filling machine has the high output speed, low consumption, convenient cleaning, and it can ensure 24-hour continuous work, thus, dramatically improves the production efficiency.
The control appliance of this making capsule equipment 000utilizes the world famous brand, modular setting, and it is very good to be checked and maintained.
This capsule filler machine has the function of printing manufacturing date, batch number, code and so on according to the requirements of buyers.
*** Why choose us?
NJP-1500D fully automatic capsule filling machine has the extremely high degree of loading precision, and extremely low error rate.
And this making capsule machine can work automatically during the whole process of capsule filling, it can dramatically save the time of clients, the clients can do other things.
During the process of capsule filling machine maintenance, 0 oil will leak, and the mold of the capsule filler equipment can be replaced freely in a very short time. During the process of capsule filling working, no damage of the capsules will be caused by the equipment.
