How To Install A Punch In A High-Speed Rotary Tablet Press

Mar 28, 2022

The high-speed rotary tablet press punch is mainly used to compress the granulated granular and powdery formula raw materials into various required round, rectangular, oval and other shapes of tablets. It is suitable for pharmaceutical factories, chemical factories, and food factories. Production and compression of various tablets, sugar tablets and calcium tablets.

The significant equipment maintenance advantage of the new punch table assembly comes from a significant reduction in the number of parts required compared to the punch table of a conventional tablet press, all of which add up to less than a 15% reduction Correction section. Significant savings in storage and parts management and maintenance of these parts costs. Using the new dynamometer assembly at the same time does not require further improvements to the high speed rotary tablet press punch, nor does it require new tooling, so replacing a new die plate does not increase the manufacturer's reliance on the tablet press .

Before installing the punch of the high-speed rotary tablet press, first remove the hopper, powder feeder, feeder frame and other parts, and wipe the working surface of the turntable, the die hole and the installed die piece by piece to prepare for the work. , follow the steps below to install.

(1) Middle mold device: Set the middle mold fixing screws on the turntable piece by piece to be level with the outer circle area of the turntable.

(2) Upper punching device: the tongue at the notch of the upper guide rail plate should be pulled up, and the tail of the middle rod should be coated with some vegetable oil, and inserted into the holes one by one.

(3) Lower punch device: open the small door on the main body, and install it from the round hole of the main body. The installation method is the same as that of the upper punch. After installation, the wafer must be flat.

(4) After the dies are all set, make the high-speed rotary tablet press run empty for 2-3 minutes, and it can be put into production smoothly and normally.
