Automatic Counting Machine For Tablet Capsule
This type of full automatic high speed counting machine for pharmaceutical can be capable of changing all sizes of bottles due to its flexible adjustment and convenient operation. All types of medical things can be freely counted and can not just for tablets but also other solid pharmacy things. It has all types of the advantages and the functions like the automatic real-time detection, the faulty alarm and many other things to ensure the quantity and the high accuracy of counting products.
*** Applications
*** Technical parameter
|
Model |
RQ-DSL-8D |
|
Vibration groove tracks |
8 lane |
|
Production capacity |
50 bottles per minute (according to the capacity of 60 capsules per bottle) |
|
Accuracy rate |
＞99.97% |
|
Filling range |
3 ～ 9999 grains |
|
Applicable target |
Tablet:Φ3～25mm ,pill:Φ3～20mm, |
|
Applicable bottle type |
Φ25～75mm round and square bottle, height ≤240 mm |
|
Voltage |
AC380V 3P 50/60HZ |
|
Power |
1.5KW |
|
Pressure |
0.4～0.6Mpa |
|
Air consumption |
105L/min |
|
Hopper capacity |
25L |
|
Weight |
405kg |
|
Outline dim.(mm) |
1100×1400×1800mm（L*W*H） |
*** Configuration List
|
No. |
Item |
Specification |
Qty. |
Manufacturer |
|
1 |
Count Photoelectric Sensor (Receive) |
N24.5R |
8 |
Lattine |
|
2 |
Count Photoelectric Sensor (Emit) |
N24.5E |
8 |
Lattine |
|
3 |
Valve Group |
M4SB10-M5-6 |
1 |
Japan CKD |
|
4 |
Filtrate Regulator |
FR500 |
1 |
Taiwan SHAKO |
|
5 |
PLC Group |
FP∑-C32TH FPO-E16YT |
1 |
Japan Panasonic |
|
6 |
Touch Screen |
GE4408W |
1 |
Japan Pro-face |
|
7 |
Cable Diffuse Sensor |
QS18VN6DB |
3 |
USA.BANNER |
|
8 |
AC Contactor |
GMC-9 |
1 |
Korea LG |
|
9 |
DC Contactor |
GMD-9 |
3 |
Korea LG |
|
10 |
Thermal Overlood Relay |
GTH-22/3 |
1 |
Korea LG |
|
11 |
Count Cylinder |
SCPS2-1030 |
8 |
Japan CKD |
|
12 |
Position Cylinder |
SDA20-10 |
4 |
AIRTAC |
|
13 |
Control Box |
131200000 |
1 |
Germany MECANO |
|
14 |
Directive Signal Light |
AL6M-P |
3 |
Japan IDEC |
|
15 |
Button Switch |
ABW310EG |
1 |
Japan IDEC |
This full automatic high speed counting machine for pharmaceutical has the functions of the automatic detection and the rejection to detect and reject all types of defected products.
So at last all the products are in standard counting production without any mistakes and this is extremely perfect for all types of countering production.
It totally meets the GMP standards rules and totally meets the standards rules of all enterprises and it has been sold to numerous countries and numerous regions and has obtained numerous praises.
*** Certification: SGS, CE, ISO, GMP
***
This full automatic high speed counting machine for pharmaceutical is easy to clean and maintain and it has zero pollution to the environment thus it is totally nice to the environment. It runs in absolutely stable operation and RQ DSL counting machine is extremely in its performance and quality and all control parts of this counter equipment are made by the famous brand materials. This counting machinery has the device of the dust collection system to collect dust centrally to rapidly reduce pollution and it is perfect in changing freely for all sizes of bottles.
