DPH-260H Automatic Medicine Blister Packing Machine By Rich Packing
The whole process of aluminum-plastic blister packaging machine adopts microcomputer programmable controller and high-end touch panel operation, which realizes frequency conversion and speed regulation of work, with high degree of automation and convenient operation. It is the ideal blister packaging equipment at present. It is usually suitable for aluminum-plastic, paper-plastic, aluminum-aluminum composite sealing packaging of capsules, tablets, honey pills, candies and special-shaped objects in the fields of pharmacy, food, electronics, medical equipment, etc.
The advantages of this machine are small footprint, low investment, multi-functional use and high efficiency. It is an ideal packaging equipment for implementing CGMP in purification workshops and hospital reagent rooms. The advantages of our RICH PACKING aluminum-plastic blister packaging machine:
1. Forming, heat sealing, indentation, punching and other components can be adjusted arbitrarily on the large platform of the DPP body to adapt to the packaging of various sizes of medicine plates.
2. The stroke of each station can be adjusted, automatic feeding, plate heating, positive pressure forming, upper and lower mesh, cylinder heat sealing, automatic indentation and batch numbering, and can be linked to mechanical hand traction to reduce labor costs.
3. According to customized requirements, a combined sub-packaging mechanism can be carried out, which is convenient for transportation and disassembly, PVC forming, feeding, and heat sealing into one section, and tropical aluminum cold forming, heat sealing, and punching into a section for separate packaging.
4. Using the latest high-power transmission mechanism of big brands, the main drive shaft is driven by the chain instead of the belt, which reduces the high error and noise caused by the belt and gear transmission.
*** Technical parameter
|
Model: |
DPH-260H |
|
Production Capacity: |
punching 40～200times/min |
|
Maximum Forming Area And Depth |
250×250*12mm |
|
Stroke Range: |
140～250mm |
|
Main Motor Power: |
2.2kW |
|
Total Power : |
18.5kW |
|
Power Supply: |
380V/220V/50Hz |
|
Standard Plate: |
80*57mm |
|
PVC Thickness/Width Thickness: |
0.15-0.30mm width 230-260 mm Film outer diameter ≤φ600 mm; Film diameter φ70-76 mm |
|
PET Aluminum Foil Thickness/Width |
thickness 0.02-0.03mm; width 230-260 mm; ; Film outer diameter ≤φ260 mm;Film diameter φ70-76 mm |
|
Dialysis Paper: |
50～100g*260mm |
|
Air Pressure : |
0.4-0.6 MPa |
|
Air Consumption: |
≥0.5m3/min |
|
Noise: |
<75dBA |
|
Cooling Water: |
it is recommended to use constant temperature cold water 60L/H |
|
Machine Weight |
3,100kg |
|
Dimensions |
4,360×1,080×2,100 mm(L×W×H) |
***Configuration List
|
Name |
Specification Model |
Manufacturer |
|
Oil-Free Vacuum Pump |
VT4.25 3Ph 0.75/0.9KW |
BECKER，GERMANY |
|
Servo Motor |
MS1H4-75B30CB-T331Z |
INOVANCE,PRC |
|
Servo Motor Software |
SV630PS5R5I |
INOVANCE,PRC |
|
PLC Main Module |
H3S-1616MT-XP |
INOVANCE,PRC |
|
PLC Extension Module |
GL10-0016ER |
INOVANCE,PRC |
|
PLC Temperature Control Module |
AX6-C |
SHENGTANG,PRC |
|
PLC Touch Screen |
6AV6/648-0BC11-3AX0 |
SIEMENS,GERMANY |
|
Encoder |
ZSP3806-003G-1500BZ3-5-24F |
AVAGO,USA |
|
Color Camera Inspection System |
SXJC-CS260H |
CELLTECH, FRENCH |
|
Main Motor (Electromagnetic Brake) |
YEJ2-100L1-4 |
WANNAN MOTOR,PRC |
|
Frequency Converter |
VFD015B43A |
INOVANCE,PRC |
|
Stainless Steel Plate |
Cr12 40Cr Gcr15 45# Q235-A |
KOREA, JAPAN |
|
Positioning Cylinder |
SDA32×10 |
AIRTAC,PRC |
|
Double Pressure Reducing Valve |
BFC4000-N |
AIRTAC,PRC |
|
The Electromagnetic Valve |
4V210-08 |
AIRTAC,PRC |
|
Pressure Reducing Valve |
AC2010-02 |
AIRTAC,PRC |
|
Emergency Button |
XB2-BS542 |
SCHNEIDER,FRANCE |
