blister packing machine

Small Tablet Blister Packing Machine

The dpp260s and dpp260l are in the same aluminum plastic blistering machine series. Dpp260s is a special aluminum plastic blister packaging machine, which can package solid materials to aluminum plastic blister board. These materials include various soft and hard capsules, tablets of various sizes, pills of various diameters, the world's best-selling e-cigarette products and the packaging of products used for various drugs and medical injections in hospitals.

  • Warranty

    2-Years
  • Product Name:

    DPP-260S Blister Packing Machine
  • Product Function:

    For Pharmaceutical and Food Blister packing
  • After-Sales Provided:

    Engineers available to service machinery overseas.
  • Certification:

    CE, SGS, ISO, etc
  • Lead Time:

    In Stock 7 Days Fast Delivery.
  • MOQ.:

    1
  • Loading Port:

    Yantian, Shenzhen / Yangshan, Shanghai
  • Product Detail

Tablet Blister Packing Machine RQ-DPP-260S




This dpp260s and dpp260l are in the same aluminum plastic blister machine series of our company. Dpp260s is a special aluminum-plastic blister packaging machine, which is used to pack solid materials into aluminum-plastic blister board. These materials include all kinds of soft and hard capsules, tablets of all sizes, pills of all diameters, best-selling e-cigarettes all over the world, all kinds of medical injections needed by medicine and hospitals, etc.


blistering machine automatic


blister packing machine


***  Technical parameter

Name DPP-260S blister packing machine

Production capacity

9650 max plates/hour

Net weight of machine

1305Kg

After warranty service

video technical support, Online support, Field maintenance and repairing.

Power

380/220V    50Hz

Total power

8.5KW



***  the PLC Siemens device Equipped in DPP260S.

All operating parameters of DPP260Scan be displayed and monitored on the PLC.

blistering packing machine



***  DPP260S use the Very convenient scale handwheel adjustment device.

The position of the DPP 260S forming hot-seal die can be adjusted only through the handle.

automatic blister packing machine



***  the Waste recycling device of dpp260S.

The remaining materials in the DPP260S production process of the aluminum-plastic blister machine will be completely recycled and not wasted.

GMP blister packing machine


***  Certification: SGS, CE, ISO

gmp capsule counter


***  Why should choose our's DPP260S blister packing machine?

Dpp260s involves several stations where the die needs to be replaced. We adopt the design of locating pin. When replacing and installing the mould, we don't need to worry about the inaccuracy of the mould and the difficulty of moving it back and forth. We fix it in two directions. We just need to push the mould that needs to be replaced, and then use the hand wheel to adjust the two directions.



Dpp260s molding station and heat sealing die station can be very simple through the hand wheel and screw the nut to complete the action of position change.



In the aspect of traction material movement, dpp260s is controlled by servo motor. By setting parameters on PLC screen, you can easily achieve the desired journey.



In order to facilitate the operation of dpp260 aluminum plastic blister packaging machine and prevent accidents, we attach great importance to safety measures, so we have designed two emergency stop functions for emergency stop switch function. In case of an accident, it can greatly reduce the time of emergency stop, so as to ensure personal safety and machine life.


capsule counting company

counting machine service

Want to know about this product?

SEND A MESSAGE
Something isn’t Clear?

Feel free to contact me, and I will be more than happy to answer all of your questions.
