NJP Automatic Capsule Making Capsule Filling Machine of Rich Packing
This model of 1500D capsule filling machine automatic can be widely used in many pharmaceutical enterprises, such as the Chinese and the Western medicine manufacturing enterprise, health care product enterprise,and etc. This kinds of capsule filler filling machine can rapidly improve the production efficiency, and the whole running process of the capsule filling working can be completed automatically. 1500D model in accord with the related rules of GMP standards, totally meets the demands of all the customers, it has zero harmful to humankind, all spare parts of the 1500D equipment that people can touch are totally safe.
These 1500D Capsule filling machine is straight forward for using, convenient for cleaning, quick to changing the molds of the machine. 1500D can working continuously in a very long time,in 24 hours and for 7 days, don not need to turn down it, just let them running, it is an ideal solution for mass capsule filling production.It can run as rapidly as it can, at a very high speed of 90,000 pcs in one hour, and it consumes little energy, creates the high output at the same time, very economic and very beneficial.
Capsule filling machine 1500D automatic has high degree of the filling capsules precision rate, the making rate of hollow capsules is up to 99.9%, and the full capsule filling good is up to 99.8%, and it is clean working without zero dirt, making very environmental. Low noise < 75 Dba can be heard during the working process of capsule filling, zero damage to the finished capsules. In addition, the Teflon coating method service can be provided for you according to the needs of the customers and the material natures.
*** Technical parameter
|
Production capacity |
90000 pcs/h |
|
Net weight of machine |
1200Kg |
|
Overall size of machine |
900×870×1950mm |
|
Power |
380/220V 50Hz |
|
Total power |
5.5KW |
|
No.of segment bores |
9 |
|
Vacuum |
40m3/h-0.04-0.08Mpa |
|
Dust collector |
24.5Kpa 210m3/h |
|
Noise |
<75DB(A) |
|
Making rate |
Empty capsule99.9% Full capsule99.8% |
|
Applicable capsule |
00,0,1,2,3,4,5# |
|
Filling error |
Western medicine:±3% Chinese medicine:±4% |
|
Applicable product |
Power、granule、pellet、tablet |
|
Packing size |
1490×1260×2150mm |
*** Configuration List
|
Item |
Specification |
Qty. |
Manufacturer |
|
Touch screen |
6AV6/648-0BC11-3AX0 |
1 |
Germany Siemens |
|
PLC |
6ES7/288-1ST20-0AA0 |
1 |
Germany Siemens |
|
AC Contactor |
3TB42 |
4 |
Germany Siemens |
|
Frequency converter |
VFD015 B21A |
1 |
Taiwan Delta |
|
Thermal relay |
3UA59 |
3 |
Germany Siemens |
|
Button |
ZB2-BA3C |
3 |
Schneider |
|
Main Motor |
CH-30-1100W |
1 |
Dongli |
|
Cam |
RU-83DS-10 RU-83DS-6 |
2 |
Taiwandaojin |
|
Vacuum pump（wet） |
SK-0.5A |
1 |
Shanghai |
|
Dust collector |
XLJ Series |
1 |
Self-made |
|
Linear bearing |
LM10UU |
40 |
Korea SAMICK |
|
Linear bearing |
LM12UU |
48 |
Korea SAMICK |
|
Linear bearing |
LM20UU |
8 |
Korea SAMICK |
|
Linear bearing |
LM40UU |
4 |
Korea SAMICK |
|
Roller bearing |
CF6B |
10 |
Japan IKO |
|
Roller bearing |
CF12B |
5 |
Japan IKO |
|
Roller bearing |
CF18B |
1 |
Japan IKO |
|
Deep groove ball bearing |
6200 |
10 |
JapanNSK |
